RATTMMOTOR 500W Spindle Motor, CNC Air Cooling Spindle Motor 52 mm 48VDC ER16 12000 RPM + 8 mm ER16 Collet for DIY CNC Engraving/Milling Machine

Product Features

• Package includes: 1 x 500 W CNC air cooling spindle motor ER16, 1 x ER16 chuck + 8 mm collet.
• Basic parameters: power: 500 W; operating voltage: 12 ~ 100 VDC; torque: 0.5 NM; collet: ER16; diameter: 52 mm; torque: 600 mN.m; insulation resistance: > 2 megohm; dielectric strength: 400 V; length of the chuck part: 35 mm for the shaft part (43mm including 43mm and collet); total length of the motor: 200 mm (including clamping part and motor).
• High speed: idle speed can reach 12000 rpm; spindle radial running 0.01-0.03 mm
• Note: the ambient air temperature: -10 ~ 40 °C; relative humidity of 85% or less, well ventilated; installed in a well-ventilated, no violent impacts, no vibrations, no explosive dangerous media and no conductive metal particles of occasions; this motor has quiet operation, cost-effective and small size of the rotation speed of the motor tail to ensure the System of the cooling fan to strengthen, you can be sure that it will work for a long time
• Application: can be used for solid wood, PCB, carving, drilling etc. Stable operation and easy replacement.
